Home :: Hobby LEDs :: Mega LED

Mega LED

Click to enlarge
Click to enlarge
Order Information
AvailabilityUsually ships in 2-3 business days
Item # mega-led
Price$2.50
Color select color
 warm white
 cool white
 red
 blue
 yellow
 green
Voltage select voltage
 3 volt battery or 3V adapter
 6-12 volt battery or regulated adapter
 7-19 Volt AC/DC/DCC(+1.00)
Wire Length 8in Wires
 14in wires(+0.10)
Qty

Buy more and SAVE!
Battery Option
Singles 2.50ea
5+2.25ea
10+ 2.15ea
Prices will update in cart
AC/DC/DCC option
Singles 3.50ea
5+3.25ea
10+ 3.15ea
Room Lighting
Accent Lighting


Our brightest LED yet! The mega is a great choice for whole room or whole building lighting.

They are small, compact, and flat for easier mounting. And very very bright!
5mm x 5mm by 2mm thick.

We have taken these SMD Chip style LEDs and taking care with tolerances, added 8 inches of red and green superfine magnet wire.

Get these chips already wired, tested, guaranteed, and fully ready to connect to your power supply. No resistors need to be added, we have done that part!


Dimensions

Choose your power supply, we have LEDs set up with correct resistors for
  • 3 volt DC
  • 9-12 volt DC
  • 7-19 volt AC/DC/DCC






"What do I need to run these?"
    3 volt use

  9 volt battery / regulated adapter

Your own AC/DC or DCC supply:
7-19V


3 volt AAA holder with switch
3 volt AA holder with switch
or our 3 Volt Adapter
9 volt get our
9 volt battery snap/switch
or plug in 12 volt get our
12 volt regulated adapter
7-19 volt Universal AC/DC/DCC lights
are already set up "plug and play"
for your own power supply


How many can run at once?
Using a 3 volt AAA holder you can run 1-20 megas
Using a 9 volt battery snap/switch you can run 1-20 of the chips.
Using a 12 volt 1 Amp supply is also 20 chips, no need to turn off.
Using your own power?
The Megas draw more than any of our other LEDs, close to 40 milliamps each. So check your power supply to see how many milliamps it lists. A 1000 milliamp supply can run 25 Megas, but likely you will not need that many!

can the Mega LEDs be run along with other LEDs from the same battery or power supply?
Yes the Megas can be run right alongside all of the other sizes of LEDs on the same power supply.
